The Multicomp Cyclone II-C

Posted by musovern on May 7th, 2018 in MultiComp Board, Single Board Computers | 0 comments

The Multicomp Cyclone II-C (v1.10) is a motherboard which provides peripheral connectivity for a Cyclone II FPGA development board commonly available on eBay. The board was designed “by committee” in the retrobrewcomputers forum during December 2015, with James Moxham doing all the actual work (schematic capture and PCB layout). One of the prime motivators for this board was to fit a 10cmx10cm footprint because the manufacturing cost of PCBs of this size is particularly attractive. It provides connectivity for the following peripherals: (v1.10) is a motherboard which provides peripheral connectivity for a Cyclone II FPGA development board commonly available on eBay. The board was designed “by committee” in the retrobrewcomputers forum during December 2015, with James Moxham doing all the actual work (schematic capture and PCB layout).
